| 产品特性：直流电机 | 是否进口：否 | 产地：韩国 |
| 加工定制：否 | 品牌：SEWOOMOTOR | 型号：DD90 |
| 产品类型：有刷直流电动机 |
| MODEL | DD90 | |||||||||||
| F012060 | F012090 | F012120 | F012150 | F024060 | F024090 | F024120 | F024150 | F090060 | ||||
Rated Voltage | V | 12 | 24 | 90 | ||||||||
Rated Output | W | 60 | 90 | 120 | 150 | 60 | 90 | 120 | 150 | 60 | ||
Rated Current | A | 7.0 | 10.6 | 14.1 | 17.6 | 3.5 | 5.3 | 7.0 | 8.8 | 0.9 | ||
Rated Speed | r/min | 3000 | ||||||||||
Rated Torque | kgf-cm | 1.9 | 2.9 | 3.9 | 4.9 | 1.9 | 2.9 | 3.9 | 4.9 | 1.9 | ||
Weight | kg | 2.1 | 2.2 | 2.9 | 3.4 | 2.1 | 2.2 | 2.9 | 3.1 | 2.1 | ||
| MODEL | DD90 | ||||||||||||
| F090090 | F090120 | F090150 | F090200 | F180060 | F180090 | F180120 | F180150 | F180200 | F180250 | ||||
Rated Voltage | V | 90 | 180 | ||||||||||
Rated Output | W | 90 | 120 | 150 | 200 | 60 | 90 | 120 | 150 | 200 | 250 | ||
Rated Current | A | 1.4 | 1.9 | 2.3 | 3.1 | 0.5 | 0.7 | 0.9 | 1.2 | 1.6 | 2.0 | ||
Rated Speed | r/min | 3000 | |||||||||||
Rated Torque | kgf-cm | 2.9 | 3.9 | 4.9 | 6.5 | 1.9 | 2.9 | 3.9 | 4.9 | 6.5 | 8.1 | ||
Weight | kg | 2.1 | 2.2 | 2.9 | 3.0 | 3.1 | 2.1 | 2.2 | 2.9 | 3.0 | 3.4 | ||
| L | MODEL |
141.5 | F012060/ /F012090 / F024060 / F024090 / F090060 / F090090 / F180060 / F180090 |
159.5 | F012120 / F024120 / F024150 / F090120 / F090150 / F180120 / F180150 / F180200 |
184.5 | F012150 / F090200 / F180250 |
